EAC Certificate Cable CU/XLPE/SWA/PE FR.A/B/C 0.6/1kV 3x240mm2 Power Cable - 副本

Applications： These power cables are used for electricity supply in low voltage installation systems. They are well adapted to underground use in industrial applications with the additional mechanical protection provided by the steel wire armor (SWA). These cables can be fixed on cable trays, within conduits or fixed to walls.

Standards：   NF C 32-321, IEC 60502-1, NF C 32-070 C2   Flame Retardant according to IEC 60332-1-2 (FR.A/B/C classification)

Technical data： Voltage Rating Uo/U 0.6/1kV   Conductor Material: Copper (CU)   Insulation Material: Cross-linked Polyethylene (XLPE)   Armour: Steel Wire Armour (SWA)   Sheath Material: Polyethylene (PE)   Cross-section: 3x240mm²   Temperature Rating   During installation -10°C to +50ºC   Fixed installation: -25°C to +90°C   Minimum Bending Radius   6 x overall diameter   Certification: EAC Certificate
