Low Voltage Cables

NYY 0.6/1KV CE Certified Cable

Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228
Insulation : PVC( Polyvinyl Chloride) rated at 70 OC
Sheath : FR-PVC(Flame retardant PVC) to IEC 60502, black
Product description: For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.
INQUIRY EMAIL

Applications:

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standards:

International: IEC 60502, IEC 60228, IEC 60332

China: GB/T 12706.1-2008

Other standards such as BS, DIN and ICEA upon request

Technical data:

Rated voltage: 0.6 / 1 kV

Maximum Conductor Temperature: under normal (70℃), emergency (130℃) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position

Min. Bending Radius: 12 x cable O.D

Certificates:

CE, RoHS, CCC, KEMA and more others at request
