Low Voltage Cables

U1000 R2V 0.6/1kV EAC cetificatesed cables

Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228
Insulation : XLPE(Cross-linked Polyethylene) rated at 90 OC
Sheath : FR-PVC(Flame retardant PVC) to IEC 60502, black
Product description: For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.
INQUIRY EMAIL

Application:

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standards:

International: IEC 60502, IEC 60228, IEC/EN 60332

China: GB/T 12706.1-2008, GB/T19666-2019

Other standards such as BS, DIN and ICEA upon request

Technical Data:

Rated voltage: 0.6 / 1 kV

Maximum Conductor Temperature: under normal (90℃), emergency (130℃) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position

Min. Bending Radius: 8 x cable O.D

Certificates:

CE, RoHS and more others at request
