Instrumentation cables

EAC DJYPVRP 300/500V

Conductor : Flexible copper conductor, Cl.5 as per IEC 60228
Insulation : PVC rated at 70 OC
Copper wire braiding screen
Sheath : PVC type ST2 to IEC 60502, black
Product description: This product is suitable for 300/500V AC voltage electric power, metallurgy, petrochemical and other industries to electronic computer-based automatic control system, computer distributed control syst
INQUIRY EMAIL

Applications

To be fixed installed in indoor, cable channel or pipe.

This product is suitable for 300/500V AC voltage electric power, metallurgy, petrochemical and other industries to electronic computer-based automatic control system, computer distributed control system, automatic control system.

Standards

International: IEC 60228, IEC 60332

China: TICW/06-2009, GB/T12666.2

Other standards such as BS, DIN and ICEA upon request.

Technical data

Rated voltage: 300/500V

Maximum Conductor Temperature: under normal (70℃).

Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position

Min. Bending Radius: 6 x cable O.D.

Certificates

CE, RoHS, CCC, KEMA and more others at request
